ZHJ-SP20 TRAY PACKING MACHINE
Short Description:
ZHJ-SP20TRAY PACKING MACHINE is especially designed for tray packing already-wrapped stick chewing gum or rectangular candy products
● Programmable motion controller, HMI, integrated control
● Servo paper plate absorbing, feeding and positioned glue spraying
● Servo candy feeding belt, pneumatic pushing tray
● Synchronous belt with pneumatic lifting function easy to clean
● Electronic glue spraying system
● Main machine mechanical overload protection
● Module design, easy maintenance and clean
● CE safety authorized
● Protection standard：IP65
● 7 motors, including 5 servo motors
Output
● Max. 20 trays/min
● Max. 1000 sticks/min
Product Measurements
● Length: Max. 152 mm
● Width: Max.108 mm
● Thickness: 20● 24 mm
Connected Load
● 15 kw
Utilities
● Compressed air consumption：5 l/min
● Compressed air pressure：0.4- 0.6 mPa
Packing Material
● Already shaped paper plate
Measurements
● Length：2735 mm
● Width：1413 mm
● Height：1835 mm
Weight
● Approx. 2000 kg
